Fast Ethernet PoE Converter Transition Networks SPOEB1013-105-NA
MPN
SPOEB1013-105-NA
UPC
648177039821
About this item
- 10/100Base-TX (RJ-45) to 100Base-FX, 1300nm, Multimode (SC), 2 km;
- Transceiver/media converter with 2 outputs expands your network capabilities;
- Data can be transferred at the desired speed and distance over optical fiber cable;
- You can receive data at up to 100Mbps over twisted pair cable with 10/100Base-TX technology;
- You can mount the device on a wall to hide it from sight;
Using the Spoeb10xx-105 10/100 Ethernet copper to fiber PoE media converter, enterprises can power existing network devices over an existing CAT5 data connection.
The Stand-alone Fast Ethernet PoE Media Converter from Transition Networks combine data received over a fiber optic link with -48 VDC power that can be used to power Data Terminal Equipment (DTE) Power Devices (PD).
Powered Devices (PDs) and Power Sourcing Equipment (PSE) are fully compatible with the IEEE 802.3af: 2003 standard.
PD signature detection and power monitoring are also included as part of the IEEE 802.3af standard. Additionally, the product includes Over-Current Protection, Under-Current Detection and Fault Protection Input.
You can enable/disable many of the features of this model as well as use the force port capability.
Additionally, a loss of Fiber RX will disable the PSE power on the UTP port for 2 seconds, allowing the remote device to reinitialize, also known as Powering Device Reset.
With the PoE converter, devices that comply with the IEEE 802.3af standard are fully supported.
PoE converters are capable of inserting power over data pairs or spare pairs of MDIs.
Specifications
Networking
| Data transfer rate (max) | 100 Mbit/s |
| Converter input interface | 10Base-T,100Base-TX |
| Converter output interface | 100Base-FX |
| Networking standards | IEEE 802.3, IEEE 802.3af |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
Ports & interfaces
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber optic connector | SC |
| DC-in jack |
Performance
| Maximum transfer distance | 2000 m |
| Wavelength | 1300 nm |
| Fiber mode structure | Multi-mode |
| Link budget | 11 dB |
Design
| Internal | |
| LED indicators | Y |
| Product colour | Black |
| Certification | EN55022:1994+A1:1996+A2:1997 |
Power
| Input voltage | 90 - 250 V |
| Power consumption (typical) | 20 W |
Weight & dimensions
| Width | 82.55 mm (3.22 ") |
| Depth | 121.92 mm (4.75 ") |
| Height | 25 mm (0.98 ") |
| Weight | 900 g (1.98 lbs) |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -25 - 85 °C |
| Operating relative humidity (H-H) | 5 - 90 % |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
SPOEB1013-105-NA by Transition Networks
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
