AXIS M5055 PTZ Security Camera

Out of stock
SKU
15_01081-001_1
$592.00
MPN
01081-001

About this item
  • 1920 x 1080 Resolution at up to 30 fps;
  • 2.2-11mm Varifocal Lens;
  • 71 to 14° Horizontal Field of View;
  • ±179° Panning & 90° Tilt;
  • 5x Optical Zoom;
  • Built-In Microphone;
  • Supports microSD/SDHC/SDXC Cards;
  • RJ45 Ethernet with PoE Technology;
  • Complies with ONVIF Profiles G & S;
  • IP51 Rated for Dust & Water Protection;

PTZ camera with 5x optical zoom that fits in the palm of your hand in HDTV 1080p

The AXIS M5055 PTZ Security Camera offers PTZ functionality and can be used in a wide range of applications, including retail, banking and offices

It's ideal for smaller installations since it provides a cost-effective method to see the overall picture - as well as all the crucial details.

See everything, and see it clearly

With a 71° horizontal field of view, the AXIS M5055 PTZ Security Camera provides good, detailed footage.

With 5x optical zoom and focusing, PTZ functionality allows you to benefit from sweeping overviews while zooming in to acquire the details

The full HDTV resolution of 1080p ensures excellent image usability.

Size is small. The cost is low

AXIS M5055 integrates discreetly into any surroundings with its subtle style and a diameter of just 130 x 63 mm (5.1 x 2.5 in).

It's available for a price that's nothing if not reasonable

Axis Zipstream technology cuts storage and bandwidth by up to 50% without sacrificing image quality, resulting in considerable cost savings.

Analytics built-in

These built-in analytics give the AXIS M5055 even more utility and versatility.

Scream detection - when the built-in microphone detects a scream in the camera's vicinity, an event is triggered

When the built-in microphone detects that a predefined volume threshold has been surpassed, an event is triggered via the Axis event system.

When a pre-selected object in the camera's field of view is removed, an event is triggered.

Video motion detection 4 - when the PTZ camera detects movement in a predetermined area of your choice, an event is triggered

This PTZ camera complies with ONVIF profiles G and S, making it compatible with a wide range of surveillance devices.

It is housed in an IP51-rated enclosure for protection from dust and dripping water.

Axis Zipstream technology lowers bandwidth and storage requirements:

  • Multiple individually configurable streams in H.264 and MJPEG;
  • Controllable frame rate and bandwidth (VBR/MBR H.264);
  • Autofocus;
  • Image settings include; resolution, compression, 0 and 180° rotation, text and image overlay, color, brightness, sharpness, white balance, wide dynamic range, exposure control, exposure time, gain, exposure zones, exposure priority, image freeze on PTZ, and privacy masks;
  • 100MB Ethernet port;
  • Built-in microphone;
  • Analytics include:AXIS Video Motion Detection, audio volume detection, scream detection, and removed object detection, with support for third-party applications;
  • Supports recording to network-attached storage and microSD card encryption;
  • Pixel counter;
  • PVC free;
  • PTZ Functions;
Specifications
Performance
Type IP security camera
Placement supported Indoor
PTZ control (Pan/Tilt/Zoom)
PTZ modes Preset point
Preset points
Wide Dynamic Range (WDR)
Number of languages 11
Languages support CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
Design
Form factor Dome
Product colour White
Mounting type Ceiling
International Protection (IP) code IP51
Housing material Plastic
Video
Maximum resolution 1920 x 1080 pixels
Video compression formats AVC, H.264, M-JPEG, MPEG4
Supported graphics resolutions 320 x 180,1920 x 1080 (HD 1080)
Full HD
Video streaming
Privacy masking
Bit rate control Variable Bit Rate (VBR)
Frame rate 30 fps
Text caption overlay
Image quality adjustment Brightness, Sharpness
Camera
Minimum illumination 1.2 lx
Viewing angle, horizontal 71 °
Viewing angle, vertical 40 °
Tilt angle range -45 - 45 °
Tilt speed 100 °/sec
Pan range -179 - 179 °
Pan speed 100 °/sec
Camera shutter speed 1/16000 - 1 s
Image sensor
Progressive scan
Sensor type CMOS
Optical sensor size 1/4.85 "
Lens system
Zoom capability
Optical zoom 5 x
Digital zoom 10 x
Maximum aperture number 2.5
Minimum aperture number 1.4
Auto focus
Focal length range (f-f) 2.2 - 11 mm
Security
Password protection
Alert notification type E-mail
Security algorithms HTTPS
Video motion detection
IP address filtering
Mirror
Storage
Card reader integrated
Compatible memory cards MicroSD (TransFlash), MicroSDHC, MicroSDXC
Built-in hard drive
Internal memory 512 MB
Flash memory 256 MB
Networking
Ethernet LAN
Ethernet interface type Fast Ethernet
Cabling technology 10/100Base-T(X)
Wi-Fi
Bluetooth
Networking standards IEEE 802.3af, IEEE 802.3at
Supported network protocols DIPv4/v6, HTTP, HTTPS, SSL/TLS, QoS L3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Ports & interfaces
Connectivity technology Wired
Interface RJ-45
Audio
Audio formats supported AAC, ADPCM, PCM
Built-in microphone
Voice codecs G.711, G.726
Weight & dimensions
Height 63 mm (2.46 ")
Diameter 130 mm
Weight 375 g (0.83 lbs)
Power
Power source type PoE
Power over Ethernet (PoE)
Power consumption (typical) 4.6 W
Power consumption (max) 7.8 W
Management features
Web-based management
Certificates
Certification EN 55032 A, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-003 A, VCCI A, RCM AS/NZS CISPR 32 A, KCC KN32 A, KN-35; IEC/EN/UL 62368-1; IEC/EN 60529 IP51
Operational conditions
Operating temperature (T-T) 0 - 45 °C
Storage temperature (T-T) -30 - 60 °C
Operating relative humidity (H-H) 10 - 90 %
Packaging content
User guide
Number of cameras 1
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 01081-001 by Axis you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
