Tripp Lite OmniVS 120V 1500VA 940W Line-Interactive UPS, Tower, USB port uninterruptible power supply (UPS)

In stock
Only 4 left
SKU
6_OMNIVS1500_1
$350.00
Eligible for Free Shipping & Free Returns
MPN
OMNIVS1500
UPC
037332126382
About this item
OmniVS 120V 1500VA 940W Line-Interactive UPS, Tower, USB port
Tripp Lite's OMNIVS1500 line interactive UPS system offers voltage regulation, surge suppression and battery support for personal computers, internetworking equipment and other sensitive electronics. Internal UPS batteries support entry level PC systems for up to 75 minutes during power failures so that connected equipment can be shut down without data loss. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 75 and overvoltages up to 147 volts back to usable 120V levels without using battery power. Offers complete desktop power protection in an attractive black tower configuration. Includes 5 battery supported outlets for computer, monitor and vital system peripherals, plus 3 additional surge suppression only outlets for printers and other system accessories not requiring battery support. USB port enables optional unattended system shutdown without data loss in the case of extended power failure (USB cable included). PowerAlert software available via free download. HID-compliant USB port also enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Built-in data line suppression offers protection for equipment with single line TEL/DSL or network Ethernet connection. Built-in audible alarm and 5 front panel LEDs indicate status of line power, battery power, battery low/replace, voltage regulation and overload. 1500VA power handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Offers 4 minutes battery runtime with a full load of 1500VA and 8.5 minutes with a half load of 750VA. Supports hot-swappable battery replacement via built-in access panel.
- OMNIVS1500 Uninterruptible Power Supply offers voltage regulation, surge suppression and long lasting battery support
- Supports entry level PCs up to 75 minutes during blackouts to enable shutdown without data loss
- Regulates brownouts as low as 75V and overvoltages to 147V back to usable 120V nominal levels without using battery power
- 5 UPS battery supported outlets, plus 3 additional surge suppression only outlets
- USB port and cable enables UPS monitoring and unattended shutdown in the case of extended power failure
- HID-compliant USB port also enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
- Data line surge suppression protects standard dialup/DSL or ethernet line connection
- Built-in audible alarm and 5 front panel LEDs indicate status of line power, battery power, battery low/replace, voltage regulation and overload
- 1500VA power handling ability supports a variety of sensitive electronic equipment
- 4 minutes full load runtime (1500VA), 8.5 minutes half load runtime (750VA)
- Supports hot swappable battery replacement via built-in access panel
- Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment
Specifications
Power
Output power capacity 1500 VA
Output power 940 W
Input operation voltage (min) 75 V
Input operation voltage (max) 147 V
Output operation voltage (max) 120 V
Power supply input frequency 60 Hz
Surge energy rating 510 J
Efficiency 97 %
Maximum current 12 A
Ports & interfaces
AC outlet types NEMA 5–15R
Power plug NEMA 5-15P
Cable length 1.8 m
AC outlets quantity 8 AC outlet(s)
USB 2.0 ports quantity 1
Battery
Battery recharge time 4 h
Typical backup time at half load 8.5 min
Typical backup time at full load 4 min
Cold start
Hot-swap battery
Design
Form factor Tower
Product colour Black
Material Polycarbonate
Performance
UPS topology Line-Interactive
Number of input phases 1
EMI/RFI noise filtering
Surge protection
Waveform Sine
Automatic Voltage Regulation (AVR)
LED indicators Y
Audible alarm(s)
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -15 - 50 °C
Operating relative humidity (H-H) 0 - 95 %
Certificates
Energy Star certified
Weight & dimensions
Width 184 mm (7.18 ")
Depth 190 mm (7.41 ")
Height 298 mm (11.62 ")
Weight 10100 g (22.27 lbs)
Package width 279 mm
Package depth 286 mm
Package height 394 mm
Package weight 10600 g
Other features
Weight (imperial) 28 lbs
Non-operating relative humidity (non-condensing) 0 - 95 %
