Trendnet TPE-TG82G Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) network switch
Free 30 Days Returns
MPN
TPE-TG82G
UPC
710931161083
About this item
8 x 10/100/1000 LAN PoE+, 128KB, 16Gbps, 110-240V AC, 50/60, 400 g
The 8-Port Gigabit PoE+ Switch, model TPE-TG82g, delivers data and power over existing Ethernet cables to Power over Ethernet (PoE) devices such as Access Points and IP Cameras. It supports both PoE and PoE+ devices with a 61W PoE budget. Plug and Play this sturdy metal switch for reliable high-speed PoE networking.
PoE Power
A 61W PoE power budget supports up to eight Power over Ethernet devices.Gigabit Ethernet
Eight gigabit ports provide a 16Gbps switching capacity to support edge network installations.Compact Design
With a compact and lightweight housing design, this switch is well-suited for desktop installations. Its fanless design is ideal for quiet environments that require silent operation. Specifications
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Networking
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Full duplex |
Data transmission
| Switching capacity | 16 Gbit/s |
| Throughput | 11.9 Mpps |
| MAC address table | 8000 entries |
| Jumbo frames support | |
| Jumbo frames | 9000 |
Design
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Certification | CE, FCC |
Performance
| Buffer size | 128 KB |
| Plug and Play | |
| Data transfer rate (max) | 2000 Mbit/s |
Power
| Power consumption (max) | 36 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Output voltage | 54 V |
| Output current | 1.67 A |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 61 W |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
Weight & dimensions
| Width | 150 mm (5.85 ") |
| Depth | 95 mm (3.71 ") |
| Height | 30 mm (1.17 ") |
| Weight | 400 g (0.88 lbs) |
Packaging content
| Quick start guide | |
| AC adapter included | |
| Cables included | AC |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
TPE-TG82G by Trendnet
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
