Trendnet TPE-2840WS Managed network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U network switch
Eligible for Free Shipping & Free Returns
MPN
TPE-2840WS
UPC
710931160208
About this item
Web Smart Switch, 28 x RJ-45, Gigabit Ethernet, PoE+/PoE
TRENDnet’s 28-Port Gigabit Web Smart PoE+ Switch, model TPE-2840WS, offers 4 x Gigabit PoE+ ports (Ports 1-4 802.3at), 20 x Gigabit PoE ports (Ports 5-24 802.3af), 4 x SFP slots, and a PoE Power budget of 185 Watts. This IPv6 ready switch offers advanced traffic management, troubleshooting, access control, energy saving GREENnet, and monitoring features at a reduced cost.
Specifications
Management features
| Switch type | Managed |
| Quality of Service (QoS) support | |
| Web-based management | |
| MIB support | MIB, MIB II |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 4 |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Gigabit Ethernet (copper) ports quantity | 24 |
Networking
| Networking standards | IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Full duplex | |
| Spanning tree protocol | |
| Flow control support | |
| 10G support | |
| Port mirroring | |
| Link aggregation |
Data transmission
| Switching capacity | 56 Gbit/s |
| Throughput | 41.7 Mpps |
| MAC address table | 16000 entries |
Virtual LAN features
| VLAN support | |
| Number of VLANs | 256 |
Multicast features
| Multicast support |
Security
| MAC address filtering | |
| Access Control List (ACL) | |
| SSH/SSL support | |
| Security algorithms | 802.1x RADIUS, SSL/TLS |
| IGMP snooping |
Protocols
| Management protocols | SNMP v1/v2c/v3, RMON v1, HTTP/HTTPS |
Design
| Rack mounting | |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Y |
| Number of fans | 3 fan(s) |
| Certification | CE, FCC |
Performance
| Buffer size | 1024 KB |
| Noise level | 54 dB |
| Mean time between failures (MTBF) | 257362 h |
Power
| Power consumption (typical) | 240.2 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) ports quantity | 20 |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 185 W |
Operational conditions
| Operating temperature (T-T) | -5 - 50 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
Weight & dimensions
| Width | 440 mm (17.16 ") |
| Depth | 250 mm (9.75 ") |
| Height | 44.45 mm (1.73 ") |
| Weight | 3800 g (8.38 lbs) |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
TPE-2840WS by Trendnet
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
