Trendnet TI-S12048 v1.0R Power supply network switch component

In stock

SKU

9_TI-S12048_1

Be the first to review this product

$127.00

Visit our Trendnet Store

MPN

TI-S12048

UPC

710931160383

About this item

Output: 120W, 48V, 2.5A, Input: 100-240V AC, 50/60Hz, 1.8A 125-370V DC, MTBF 2.899.000h, 670g

Description
Specifications

TRENDnet’s high efficiency 120 W Single Output Industrial DIN-Rail Power Supply, model TI-S12048 (Mean Well SDR-120-48), supplies up to 120 Watts (48 V, 2.5 A) of power to industrial PoE equipment such as switches, network cameras, and WiFi access points. This power supply comes with active PFC, an integrated DIN-rail mount, and overload current protection.

120 Watt Power

Provides up to 120 Watts (48 V, 2.5 A) of power for PoE devices such as switches, network cameras, and access points

Active PFC

The built-in active Power Factor Controller (PFC, PF > 0.93) helps eliminate unusable reactive power

Overload Protection

Overload/short circuit/over voltage/over temperature protection

Full Load Test

This power supply undergoes a 100 % full load burn-in test

Passive Cooling

Cooling by free air convection

DIN-Rail Mount

Metal enclosure with integrated DIN-rail mount

Extreme Temperatures

Rated for an operating temperature range of -25 to 70 °C (-13 to 158 °F)

Safety Certifications

Certified for UL 508 and TUV EN60950-1

Electro Magnetic Emission/Immunity

Compliance to EN55011, EN55022 (CISPR22), EN61204-3 Class B, EN61000-3-2/3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, EN61000-6-2, EN61204-3, heavy industry level, criteria A, SEMI F47, and GL approved

Vibration Resistant

Rated for vibration

LED Indicator

LED indicator confirms power to the unit

Specifications

Features

Product type	Power supply
Product colour	Metallic
LED indicators	Y
Power protection features	Over voltage, Overload, Short circuit
Mean time between failures (MTBF)	2899000 h
Certification	CE, UL, TUV

Power

Total power	120 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	1.8 A

Operational conditions

Operating temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	0 - 90 %

Weight & dimensions

Width	40 mm (1.56 ")
Depth	125 mm (4.88 ")
Height	114 mm (4.45 ")
Weight	670 g (1.48 lbs)
