Tenda TEG1024G Unmanaged network switch Blue network switch
MPN
TEG1024G
UPC
885397030072
About this item
24-Port Gigabit Ethernet Switch, IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3x, full-duplex & flow control, NMA auto-negotiation, UPnP, 8K MAC Address Table, 10/100/1000Mbps, 48Gbps Backplane Bandwidth, 24x RJ45
The TEG1016G and TEG1024G are 16 and 24 port 1U rack-mountable Gigabit switches respectively. They support auto MDI/MDIX and store-and-forward switching. The TEG1016G has a 32Gbps backplane bandwidth while the TEG1024G has a 48Gbps backplane bandwidth. These switches are ready for deployment in server rooms or offices with a need to keep serious network traffic flowing.
- Complies with IEEE 802.3x full-duplex and flow control.
- NMA auto-negotiationSupports UPnP.
- Provides 16 (TEG1016G)/24 (TEG1024G) auto-negotiation 10/100/1000Mbps LAN ports.
- Supports auto MDI/MDIX.
- Non-blocking.
- Store-and-forward switchingIntegrated 8000 MAC address table.
- Internal power supply.
- Standard 19” rack-mountable metal case.
- Complies with IEEE 802.3x full-duplex and flow control.
- NMA auto-negotiationSupports UPnP.
- Provides 16 (TEG1016G)/24 (TEG1024G) auto-negotiation 10/100/1000Mbps LAN ports.
- Supports auto MDI/MDIX.
- Non-blocking.
- Store-and-forward switchingIntegrated 8000 MAC address table.
- Internal power supply.
- Standard 19” rack-mountable metal case.
Specifications
Management features
| Switch type | Unmanaged |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Gigabit Ethernet (copper) ports quantity | 24 |
| ExpressCard slot |
Networking
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Full duplex | |
| Auto MDI/MDI-X | |
| 10G support | |
| Flow control support |
Data transmission
| Supported data transfer rates | 10/100/1000 Mbps |
| MAC address table | 8000 entries |
| Maximum data transfer rate | 1 Gbit/s |
Security
| MAC address filtering |
Design
| Rack mounting | |
| Product colour | Blue |
| Housing material | Metal |
| LED indicators | Link, Power |
| Certification | CE, RoHS |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) |
Operational conditions
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 95 % |
Other features
| Dimensions (WxDxH) | 208 x 440 x 44 mm |
| Connectivity technology | Wired |
| Bandwidth | 48 Gbit/s |
| Wi-Fi | |
| Size | 19 " |
| Networking features | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Input frequency | 50/60 Hz |
| Power LED | |
| Input voltage | 100 - 240 V |
