StarTech.com 4PORT-8K-HDMI-SWITCH video switch
Free 30 Days Returns
MPN
4PORT-8K-HDMI-SWITCH
UPC
065030899420
StarTech.com 4PORT-8K-HDMI-SWITCH video switch
Specifications
Ports & interfaces
| Video port type | HDMI |
| HDMI ports quantity | 5 |
| HDMI version | 2.1 |
| HDMI in | 4 |
| Number of HDMI outputs | 1 |
| USB port type | Micro-USB |
Features
| Product colour | Black |
| Maximum operating distance | 5 m |
| Supported graphics resolutions | 1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1080,2560 x 1440,3440 x 1440,4096 x 2160,5120 x 1440,7860 x 4320 |
| HDCP version | 2.3 |
| LED indicators | Y |
| Dolby technologies | DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby TrueHD |
| External power adapter | |
| Audio output channels | 7.1 channels |
| Bandwidth | 48 Gbit/s |
| HDCP | |
| Material | Metal |
| Plug and Play |
Power
| AC input voltage | 100 - 240 V |
| AC adapter input current | 0.3 A |
| AC adapter output voltage | 5 V |
| AC adapter output current | 1 A |
| Power consumption (typical) | 5 W |
Weight & dimensions
| Width | 61 mm (2.38 ") |
| Depth | 136 mm (5.3 ") |
| Height | 14 mm (0.55 ") |
| Weight | 150 g (0.33 lbs) |
Packaging data
| Package width | 123 mm |
| Package depth | 179 mm |
| Package height | 50 mm |
| Package weight | 420 g |
Packaging content
| Mounting kit | |
| Cables included | USB Type-A to Micro-USB Type-B |
| AC adapter included | |
| Quick start guide | |
| Handheld remote control |
Operational conditions
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 5 - 90 % |
Logistics data
| Master carton width | 400 mm |
| Master carton length | 550 mm |
| Master carton height | 280 mm |
| Quantity per master carton | 40 pc(s) |
Other features
| Y | |
| CE, RoHS | |
| Y |
