Peerless SP850-UNL 65" flat panel wall mount

Pull-Out Swivel Mount for 26"- 50" LCD and Plasma Screens

The SmartMount® Pull-Out Swivel Wall Mount combines the best features of a wall mount and a pivot arm. In the closed position, the SP850-UNL acts as a flat or tilting wall mount. At only 3.4" away from the wall, its unique wall plate and built-in cable management neatly hide all components and cords. Extended, the SP850’s sturdy arm construction smoothly glides the screen out 11.9" from the wall and allows the screen to pivot up to 45 degrees. This feature not only enables the screen to be positioned for an optimal viewing angle, but it also provides easy access to the back of the screen for maintenance. The SP850-UNL is also ideal in applications where the screen needs to be recessed into a cubby hole, custom frame or aligned into a video wall. Mounts to 16" wood studs, concrete or cinder block.
- Includes universal adapter plate for mounting holes up to 28.75 W x 17.05H
- Pull-out swivel with up to 45° rotation depending on screen size
- Locking tab provides optional swivel restriction to one side
- 3.4" deep in closed position, up to 11.9" fully extended
- 0°, 5° or 10° lockable incremental tilt
- +/-1° roll for horizontal screen alignment during installation
- Built-in cord management
- Lock Key™ installation tool secures arms for screen installation
- Lock-out screw prevents unwanted extension
- Mounts to 16" wood studs, concrete, cinder block
- Includes mounting and screen attachment hardware
