Cooler Master SickleFlow 80 Computer case Fan 8 cm BK
MPN
MFX-B8NN-25NPK-R1
UPC
884102079238
About this item
650-2500 RPM, 30 CFM, 2.75 mmH2O, 6 - 25 dBA, 80 mm, 12VDC, 4-Pin, 83 g
Optimized Flow and Pressure
nContinuing the SickleFlow 120 series , Cooler Master introduces a new models with brand new upgraded design features for enhanced performance.The new SickleFlow 80 fan blades are created with bigger blades and increased curvature to optimize the air flow and air pressure performance. Strengthen structural frame design with added rib housing for durability. Improved dustproof and oil leakage prevention for beater life expectancy.Improved Frame Durability
nEnhanced square frame structure with added rib-support for reducing turbulent flow, noise and increasing overall work efficiency.New Air Balance Blade
nOptimized fan blade design with increased curvature that improves air flow and air pressure.New Bearing Sealant
nTwo-tier sealing mechanism designed to improve dustproof capabilities and prevent lubricant oil leakage for extended life span and performance. Specifications
Performance
| Type | Fan |
| Fan diameter | 80 mm |
| Rotational speed (min) | 650 RPM |
| Rotational speed (max) | 2500 RPM |
| Noise level (low speed) | 6 dB |
| Noise level (high speed) | 25 dB |
| Maximum airflow | 30 cfm |
| Maximum air pressure | 2.75 mmH2O |
| Pulse-width modulation (PWM) support | |
| Bearing type | Rifle bearing |
| Number of fans | 1 fan(s) |
| Fan connector | 4-pin |
Design
| Product colour | Black |
Power
| Power consumption (typical) | 1.32 W |
| Rated voltage | 12 V |
| Rated current | 0.11 A |
| Safety current | 0.18 Ah |
Weight & dimensions
| Width | 80 mm (3.12 ") |
| Depth | 25 mm (0.98 ") |
| Height | 80 mm (3.12 ") |
| Weight | 83 g (0.18 lbs) |
| Package width | 32 mm |
| Package depth | 115 mm |
| Package height | 170 mm |
| Package weight | 136 g |
Logistics data
| Master carton width | 360 mm |
| Master carton length | 380 mm |
| Master carton height | 267 mm |
| Quantity per master carton | 40 pc(s) |
Other features
| 160000 | |
| Computer case |
