Black Box IC400A-R2 network extender Network transmitter & receiver

SKU

6_IC400A-R2_1

Be the first to review this product

$513.00

Visit our Black Box Store

MPN

IC400A-R2

UPC

822088123101

Get USB connectivity anywhere.

Install your USB devices anywhere! Combine the USB Ultimate Extender over UTP with additional USB hubs to power up to 30 USB devices. It supports all major operating systems including Windows, Mac OS, and Linux. It's truly plug-and-play, ready to operate right out of the box. No new driver installation is required. The USB Ultimate Extender works with all USB device types: control, interrupt, bulk, and isochronous at up to 480 Mbps. It’s ideal for a wide variety of USB devices, including printers, scanners, hard drives, audio devices, touch screens, and Web cams. The 2-port version IC402A-R2 with remote power delivers power to the remote hub over CAT5 cable, simplifying installation and eliminating the need for AC power close to the remote unit. The remote unit provides 750 mA to each USB port. The 4-Port model IC400A-R2 features an AC power adapter at the remote unit provides 1A to each USB port, up to 600mA when all four ports being used. The local unit doesn’t require power for normal operation. The USB Ultimate Extender over UTP is ideal for variety of USB devices, from printers, scanners, hard drives, and audio devices, touch screens, Web cams, and more. Use it for any or all of the following applications:
- Industrial control
- KVM extension
- Digital signage
- Remote desktop USB connections
- Security: Web camera, access control
- Medical Device connectivity
- USB Web device sharing: printing, scanning, storage

Specifications

Performance

Type	Network transmitter & receiver
Maximum transfer distance	100 m
Plug and Play
Windows operating systems supported	Y
Mac compatibility
Linux operating systems supported	Y

Ports & interfaces

Ethernet LAN (RJ-45) ports	1
DC-in jack
USB 2.0 ports quantity	4

Design

Product colour	Black
LED indicators	Y
Certification	FCC (Class B), IC (Class B), CE (Class B); ESD Rating: EMC EN-61000-4-2:2001 4kV Contact, 8kV Air

Operational conditions

Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight & dimensions

Weight	1000 g (2.2 lbs)
Transmitter width	100 mm
Transmitter depth	76 mm
Transmitter height	26 mm
Receiver width	100 mm
Receiver depth	76 mm
Receiver height	26 mm

Packaging content

Cables included	USB
AC adapter included
