ASUS ThunderboltEX 4 with Intel Thunderbolt 4 JHL 8540 Controller
Eligible for Free Shipping & Free Returns
MPN
90MC09P0-M0EAY0
UPC
195553115254
About this item
- Intel Thunderbolt 4 JHL 8540 controller;
- Ultrafast connectivity: Two Type-C ports with USB 4 support, up to 40Gb/s bi-directional bandwidth, per port allows you to connect up to five Thunderbolt-enabled devices in a daisy-chain configuration using Thunderbolt cables;
- DisplayPort 1.4: support up to 8K resolution monitors;
- Quick charge solution: up to 100W quick charge;
Enable blisteringly fast speeds and any-way-up connectivity
ASUS ThunderboltEX 4 is a Thunderbolt 4 add-on card that offers 40 Gbps bi-directional bandwidth, USB4™ device compatibility, and DisplayPort™ 1.4.
It supports up to five Thunderbolt devices in a daisy chain and enables up to 100-watt USB-C® charging for laptops.
Specifications
Ports & interfaces
| Internal | |
| Host interface | PCIe |
| Output interface | Mini DisplayPort, PCIe, Thunderbolt, USB 2.0, USB 3.2 Gen 2 (3.1 Gen 2) |
| Expansion card standard | PCIe 3.0 |
| USB 2.0 ports quantity | 1 |
| USB 3.1 (3.1 Gen 2) Type-C ports quantity | 2 |
Performance
| Plug and Play | |
| Purpose | PC |
| Chipset | Intel Thunderbolt 4 JHL8540 |
| Data transfer rate (max) | 40 Gbit/s |
| Product colour | Black |
System requirements
| Windows operating systems supported | Windows 10 x64 |
Weight & dimensions
| Width | 117.7 mm (4.59 ") |
| Depth | 180.5 mm (7.04 ") |
Packaging content
| Quantity | 1 |
| Cables included | Mini DisplayPort, Thunderbolt, USB |
| Drivers included | |
| Manual | |
| Package type | Box |
Other features
| Compatibility | ASUS Intel 500 |
| 7680 x 4320 |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
90MC09P0-M0EAY0 by ASUS
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
