Hanwha QNE-8011R security camera IP security camera Indoor & outdoor Dome Ceiling/Wall 2560 x 1944 pixels
In stock
SKU
15_QNE-8011R_1
Special Price
$358.00
Regular Price
$500.00
Eligible for Free Shipping & Free Returns
MPN
QNE-8011R
About this item
QNE-8011R, 1/2.8" 5MP CMOS, 2592x1944, IR, WDR, RJ-45, Micro SD/SDHC/SDXC, IP67, PoE, 125x87.35 mm
- Max. 5Megapixel (2592 x 1944) resolution
- 2.8mm fixed lens
- 0.15Lux (Color), 0Lux (B/W, IR LED on)
- Max. 30fps@5MP (H.265 / H.264)
- H.265, H.264, MJPEG codec support, Multiple streaming
- Day & Night, WDR (120dB)
- Tampering, Motion detection, Defocus detection
- Micro SD / SDHC / SDXC memory slot (Max. 128GB)
- Hallway view, WiseStream II support
- IR Viewable length 20m
- LDC, PoE
- 2.8mm fixed lens
- 0.15Lux (Color), 0Lux (B/W, IR LED on)
- Max. 30fps@5MP (H.265 / H.264)
- H.265, H.264, MJPEG codec support, Multiple streaming
- Day & Night, WDR (120dB)
- Tampering, Motion detection, Defocus detection
- Micro SD / SDHC / SDXC memory slot (Max. 128GB)
- Hallway view, WiseStream II support
- IR Viewable length 20m
- LDC, PoE
Specifications
Performance
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | |
| Day/night mode | |
| Infrared (IR) cut-off filter |
Design
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling/Wall |
| Housing material | Aluminium |
| IK code | IK10 |
| International Protection (IP) code | IP67 |
Video
| Maximum resolution | 2560 x 1944 pixels |
| Total megapixels | 5 MP |
| Video compression formats | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 640 x 360,640 x 480 (VGA),720 x 480,720 x 576,800 x 448,800 x 600 (SVGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2592 x 1944 |
| Noise reduction | |
| Privacy masking | |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | |
| Video streaming | |
| Frame rate | 30 fps |
| Flip & mirror |
Camera
| Camera pan control | |
| Camera tilt control | |
| Viewing angle, horizontal | 104.4 ° |
| Viewing angle, vertical | 76.7 ° |
| Viewing angle, diagonal | 136.1 ° |
| Tilt angle range | 0 - 75 ° |
| Pan range | 0 - 350 ° |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Angle of rotation | 360 ° |
| Camera shutter speed | 1/5 - 1/12000 s |
Image sensor
| Number of sensors | 1 |
| Number of effective pixels (H x V) | 2592 x 1944 pixels |
| Sensor type | CMOS |
| Optical sensor size | 1/2.8 " |
Lens system
| Number of lenses | 1 |
| Maximum aperture number | 2 |
| Fixed focus | |
| Fixed focal length | 2.8 mm |
Security
| Intelligent Video Surveillance (IVS) system features | Defcous |
| Anti-flicker | |
| Security algorithms | EAP-TLS, HTTPS, LEAP, SSL/TLS |
| Video motion detection | |
| Mirror | |
| IP address filtering |
Storage
| Card reader integrated | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Built-in hard drive | |
| Flash memory | 256 MB |
| Internal memory | 512 MB |
| Maximum memory card size | 128 GB |
Night vision
| Night vision | |
| Night vision distance | 20 m |
| LED type | IR |
Networking
| Ethernet LAN | |
| Ethernet interface type | Fast Ethernet |
| Wi-Fi | |
| Bluetooth | |
| Networking standards | IEEE 802.1x, IEEE 802.3af |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
| Streaming method | Multicast, Unicast |
| Quality of Service (QoS) support |
Ports & interfaces
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
Weight & dimensions
| Height | 87.35 mm (3.41 ") |
| Diameter | 125 mm |
| Weight | 645 g (1.42 lbs) |
Power
| Power source type | PoE |
| Power consumption (Power over Ethernet (PoE)) | 7.4 W |
| Power consumption (typical) | 5.5 W |
Operational conditions
| Operating temperature (T-T) | -30 - 55 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
System requirements
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave |
Packaging content
| Number of cameras | 1 |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
QNE-8011R by Samsung
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
