Trendnet TEG-10GBSR Fiber optic 850nm 10000Mbit/s SFP+ network transceiver module

In stock

SKU

9_TEG-10GBSR_1

Be the first to review this product

$46.00

Visit our Trendnet Store

MPN

TEG-10GBSR

UPC

710931140170

About this item

SFP+, 10GBASE-SR, 10.5 Gbps, 850 nm, 550 m

Description
Specifications

TRENDnet’s hot-pluggable TEG-10GBSR, 10GBASE-SR SFP+ Multi Mode LC Module, works with a MSA compliant SFP+ slot. This Multi Mode transceiver spans distances up to 550 meters (1,804 feet), comes with a LC duplex connector, and supports up to 10.5 Gbps networking throughput speeds. Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/receive power, temperature, and voltage.

Hot-Pluggable SFP+

Hot-pluggable SFP+ transceiver works with a MSA compliant SFP+ slot

Fiber Wavelength

Compatible with Multi Mode 850 nm transmissions

Fiber Distance

Supports networking for distances up to 550 meters (1,804 feet)

Fiber Port

LC-type duplex connector

DDM Support

Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/receive power, temperature, and voltage

Power Supply

Single 3.3 volt power supply

Operating Temperature

Rated for an operating temperature range of 0 to 70 °C (32 to 158 °F)

Standards

Compliant with SFF-8431, SFF-8432, SFF-8472, FC-PI-4,10G FC, and IEEE802.3ae 10GBASE-SR

Specifications

Networking

Data transfer rate (max)	10000 Mbit/s
Interface type	SFP+
Fiber optic connector	LC
Networking standards	IEEE 802.3ae
SFP transceiver type	SR
Fiber ports quantity	1

Performance

Cable type	Fiber optic
Multi-mode fiber (MMF) supported
Wavelength	850 nm
Hot-Plug support
Maximum transfer distance	550 m

Power

Power consumption (typical)

0.439 W

Operational conditions

Operating temperature (T-T)	0 - 70 °C
Operating relative humidity (H-H)	0 - 95 %

Weight & dimensions

Width	14.8 mm (0.58 ")
Depth	56.5 mm (2.2 ")
Height	11.85 mm (0.46 ")
Weight	22 g (0.05 lbs)
